ARLON® Self-Fusing Silicone Tapes: Electrical Insulation and Flame-Resistant Protection
When electrical connections, cables, and components operate in demanding environments, the materials used to protect them need to do more than provide a basic covering. They may need to withstand heat, resist moisture and ozone, conform around irregular shapes, and maintain reliable electrical insulation.
ARLON® Self-Fusing Silicone Tapes from Rogers Corporation are engineered to create a continuous insulating barrier by bonding to themselves rather than relying on a conventional adhesive. This makes them a useful option for selected electrical insulation, protective wrapping, and industrial applications where conformability and environmental resistance are important.
Rogers also offers ARLON FR, a flame-resistant version designed for applications with additional flame-performance requirements. Understanding the differences between product constructions, their installation requirements, and their technical specifications helps engineers determine whether an ARLON tape is suitable for a particular design.
For manufacturers developing application-specific components, ABLE Industrial Products provides custom converting expertise to help evaluate material options and production requirements.
What Are ARLON Self-Fusing Silicone Tapes?
ARLON Self-Fusing Tapes are made from specially formulated silicone rubber. When the tape is stretched and wrapped so that its surfaces make intimate contact, it begins to fuse to itself, forming a continuous silicone covering.
Unlike conventional pressure-sensitive electrical tape, the self-fusing mechanism does not depend on a traditional adhesive layer bonding the tape to the underlying component. The finished tape remains non-tacky against other surfaces and can generally be removed from the wrapped substrate without leaving adhesive residue.
However, once the tape has fused to itself, it cannot be separated intact. Rogers explains that the fusion begins immediately but may take up to 24 hours at room temperature to form a fully homogeneous mass, depending on the product.
According to Rogers, ARLON Self-Fusing Silicone Tapes are designed to provide electrical insulation and resistance to moisture, oxygen and ozone. Product options vary by construction, thickness, profile, and performance characteristics.
Key Benefits of ARLON Self-Fusing Silicone Tapes
The right self-fusing tape can help address several material and installation challenges. The exact benefits depend on the selected product grade and how it is applied.
1. Electrical insulation
ARLON Self-Fusing Silicone Tapes are designed for electrical insulation applications. Once correctly wrapped and fused, the silicone material creates an insulating barrier around the covered area.
This can make the tape worth evaluating for wire and cable protection, electrical connections and other applications requiring an insulating silicone covering.
Electrical performance varies by product construction and thickness. Engineers should check the applicable dielectric strength, volume resistivity and required electrical standards before specifying a tape.
2. Resistance to moisture and ozone
Moisture and ozone can affect the performance and service life of materials used around electrical equipment and industrial components.
Rogers identifies resistance to moisture, oxygen and ozone as key characteristics of its ARLON self-fusing silicone tapes. These properties can make suitable grades relevant to applications where environmental exposure is a consideration.
The finished assembly’s overall protection will also depend on the wrapping method, coverage, component geometry and operating environment.
3. Conformability around complex shapes
Electrical connections and industrial components do not always have simple, uniform surfaces. A protective material may need to wrap around bends, irregular profiles and different component diameters.
ARLON tapes are designed to conform smoothly around complex forms when applied correctly. The self-fusing construction allows the material to create a continuous covering across the wrapped area.
This conformability can be useful when a conventional rigid covering would be difficult to install.
4. Wide operating temperature range
Silicone materials are often selected for applications involving demanding temperature conditions. Rogers’ ARLON product portfolio includes self-fusing tapes designed for a wide operating temperature range.
The exact limits are product-specific. The standard ARLON and flame-resistant ARLON FR products should not automatically be assumed to share the same temperature rating. Always use the current technical data sheet for the precise part number being considered.
5. No conventional adhesive layer
ARLON Self-Fusing Tapes bond to themselves through their self-fusing chemistry rather than a conventional pressure-sensitive adhesive.
This construction offers several practical advantages:
- The tape remains non-tacky when touching other substrates.
- The material can be removed from the underlying surface without typical adhesive residue.
- The fused tape forms a continuous covering around the wrapped area.
- The tape can conform around suitable irregular shapes.
Because the bond is designed to be permanent between contacting tape surfaces, proper positioning and wrapping are important during installation.
How to Install ARLON Self-Fusing Silicone Tape Correctly
Correct installation is essential because the tape needs intimate contact with itself to fuse. Rogers’ Self-Fusing Tape Installation Guide provides the following general method.
- Step 1: Prepare the Application Area
Inspect the component and remove contaminants that could affect installation. Ensure the area is suitable to help prevent contaminants from becoming trapped beneath the wrap.
- Prepare the tape. Unwind the required length and remove the polymer release liner.
- Wrap and stretch. Apply the tape around the component while stretching it as directed by the installation instructions.
- Double-wrap the first loop. This helps establish the initial wrap.
- Continue with half-laps. Keep elongating the tape and wrap with overlapping half-laps until the required area is covered.
- Finish the final wrap. Rogers’ guide specifies slight elongation for the final full lap: approximately 50% for unsupported tapes and 5–10% for reinforced tapes.
These elongation figures are from the supplied installation guide and should be followed in context with the specific product instructions.
Keep the contact surfaces clean
Dirt, oil and grease can prevent the tape surfaces from making the intimate contact needed for fusion. The surfaces and tape should therefore be kept clean during application.
The tape begins fusing immediately, but the guide notes that full fusion can take up to 24 hours at room temperature. Once fused, the tape cannot be removed intact.
For the full illustrated process, consult Rogers’ Self-Fusing Tape Installation Guide.
How to Select the Right ARLON Tape
Not every ARLON product is interchangeable. Before specifying a tape, engineers and purchasing teams should review several factors.
Electrical requirements: Determine the required dielectric strength, insulation thickness, and applicable electrical standards.
Temperature and environmental exposure: Review the actual operating temperature range and exposure to moisture, ozone, corona, or other environmental conditions.
Flame-performance requirements: If flame resistance is required, confirm the specific product’s rating, test documentation, and relevant qualification requirements.
Tape construction: Consider whether a rectangular, triangular, supported or reinforced construction is appropriate for the geometry and installation method.
Thickness and coverage: Evaluate the amount of insulation required, available space and how the tape will conform around the component.
Installation and serviceability: Consider access, wrapping technique, the time needed for fusion, and whether the tape may need to be removed or replaced in the future.
The attached ARLON FR sell sheet lists product-specific details, including a UL 94 V-0 rating and references to certain transportation and flame standards. Because product data can vary by grade and documentation revision, engineers should verify all specification values against the latest Rogers data sheet before making a final selection.
How ABLE Industrial Products Supports Custom Converting
Selecting the right tape is only part of developing a reliable component. ABLE Industrial Products supports manufacturers with custom converting capabilities for demanding industrial applications. As a Rogers Preferred Converter, ABLE can help customers evaluate suitable Rogers materials and develop converted components based on their application requirements.
Depending on the design and material, converting options may include:
- Rotary and flatbed die cutting: Produces custom shapes for component-specific designs.
- Kiss cutting: Supports parts supplied on a liner for handling and application.
- Laser cutting: Offers another option for producing precision-cut profiles.
- Slitting: Converts material into narrower widths as required.
- Laminating: Combines compatible materials to create multilayer constructions.
- Prototype development: Helps evaluate part designs and converting requirements before production.
Discuss Your ARLON Tape Application with ABLE
ARLON Self-Fusing Silicone Tapes offer an option for applications that require a conformable silicone covering, electrical insulation, and resistance to selected environmental conditions. ARLON FR provides an additional option for designs with specific flame-performance requirements.
The key is to match the product grade and construction to the actual operating environment, installation method, and qualification requirements.
ABLE Industrial Products helps manufacturers evaluate engineered materials and custom converting options for demanding industrial applications. Contact ABLE to discuss your component requirements, material compatibility, and potential path from design evaluation to production.
